Expert printing made easy

Low Cost. High Return.

JV100-160 Solvent printer

Built in response to market demands, the JV100-160 makes high quality solvent printing available at an entry-level price. Mimaki’s proven technology featured in this new printer advances ease of use, and with the possibility to load 8 different colours, high definition colour reproduction comes standard. Having an EU and a non-EU model available, Mimaki offers tailor made solutions for the greater EMEA region.

Highlighted features

2 models available
The JV100-160 is available in a bottle ink and a cartridge ink model.
The 1L bottle ink model, available for the NON-EU region, comes in a 4 colour configuration, while the cartridge model comes in a 4 and 8 colour configuration. Both versions with all Mimaki Core Technologies on board.

DAS system
Performs both a bi-directional and media feed adjustment.
Introducing Mimaki’s -easy to operate- Dot Adjustment System (DAS), which automatically performs two adjustments: the bi-directional adjustment and the media feed adjustment.

The bi-directional adjustment assures the drop landing accuracy for a perfect round dot, resulting in the highest possible print quality.

The media feed compensation optimises the feeding of the media, eliminating horizontal banding.

ID Cut with cutter combo
Combine the JV100-160 with a Mimaki cutter for seamless integration using the ID cut workflow.
Maximise the flexibility of your production and combine the JV100-160 with a Mimaki FXII cutter, seamlessly integrated using the ID-Cut workflow.

Simply print a barcode with each print & cut job and benefit from an automated continuous workflow without the intervention of an operator.

Without ID cut

With ID cut

RasterLink7
Developed to design your own favourite menu settings – is user friendly and now equipped with variable data printing.
RasterLink7 comes in the box and has upgraded features over RasterLink6 plus. It uses a new RIP core with 25% faster processing time of complex PDF files.

Bottle version

Cartridge version

Designed to produce a wide range

of materials and applications

Vehicle wrapping, Outdoor and Indoor Signage, Window Signage, Backlit, Banners, Posters, Canvas, Wallpaper, Labels & Decals, Floor Stickers, POS-display, Transfer Material and more.

Solvent ink technology

for superior quality

The JV100-160 comes with a wide range of solvent inks, from 4 colours up to 8 colours. Mimaki’s fast drying solvent inks, known for its excellent weather ability and rub-fastness is available for the JV100-160 in 4 colour BS4 and CS250, and 8 colour SS21 and newly developed low-priced AS5.

With this new printer, Mimaki is offering a solution for each customer with such a wide range of different ink types and ink configurations to choose from. From low-cost inks in 4 and even 8 colours, the JV100-160 is the most competitive printer in the market, guaranteeing your highest profit.

For even more confidence

our products are certified

GREENGUARD GOLD certified products meet the rigorous standards for low emission of volatile organic compounds (VOCs) and ensures that a product is acceptable for use in environments such as schools and healthcare facilities without polluting the indoor air quality.

Our SS21, BS4, AS5, CS250 are GREENGUARD GOLD certified.

Mimaki’s JV100-160 compatible SS21 mild solvent ink meets the chemical requirements of the Nordic Swan Ecolabel program for printing companies.

Mimaki’s SS21, BS4 and AS5 eco-solvent inks are compliant with the Avery Dennison ICS Performance Guarantee Program.

The ICS Performance Guarantee assures the performance of Avery films with a printing platform when customers are working according to the relevant Avery Dennison Technical Bulletins associated with that product.

This printer includes Mimaki Core Technologies that offer the best print quality, maximum productivity and reduced exposure to risks that can delay production. See below list of core technologies that are included in the JV100-160.

Productivity & Convenience

Nozzle Check Unit (NCU), to detect missing nozzles
Nozzle Recovery System (NRS), to replace missing nozzles
Automatic Cleaning Fun ction, to keep the print head clean
Automatic Wi p er Cleaner, to keep the wiper clean
Jam Sensor, to prevent print head damage

Quality printing

Mimaki Advanced Pass System 4 (MAPS), to reduce banding
Waveform C ontrol (WFC), for best possible image sharpness
Variable Dots Technology (VDT), for smoother gradations
Mimaki Fine Diffusion (MFD), for smoother colours
Dot Adjustment System (DAS), for stable printing

Model	JV100-160C	JV100-160B
Print head	2 drop-on-demand piezoelectric head; stagger arrangement
Print resolution	Y: 360 dpi, 720 dpi, 1200dpi; X: 600dpi, 900 dpi, 1200dpi
Drop size	Min: 4pl, Max: 20pl
Head height	Manual adjustment (2.0/2.5mm from platen)
Ink type	SS21: CMYK / CMYKLcLmLkOr AS5: CMYK / CMYKLcLmLkOr BS4: CMYK	CS250: CMYK
Ink colour	4C (CMYK) / 8C (CMYKLcLmLkOr)	4C (CMYK)
Ink supply	600ml ECO ink pack / 2000ml* Ink bag	1L bottle supply
Max printing width	1,610mm
Max media width	1,620mm
Media thickness	1.0mm or less
Outside diameter	250mm or less
Roll weight	45kg or less
Take-Up	Included
Interface	USB2.0 / Ethernet
Body weight	166kg	168kg
Dimension (WxDxH)	2775/700/1392mm	2775/700/1475mm
Power supply	2 x Single phase (AC100~120/200~240V +/- 10%, 50/60Hz +/- 1Hz)
Power consumption	AC100V: 1.44kW / AC200V:1.92kW
Safety Standards	VCCI class A, FCC Class A, CE Marking (EMC Directive, Machinery and Low Voltage Directive), CB Certification, RoHS, RCM, EAC

*2000ml ink pack requires a purchase of MBIS3 ink bulk system

Software RIP

Mimaki’s dedicated software RIP, Rasterlink 7, comes in the box.

Rasterlink 7

Rasterlink 7 has new functionality and upgraded speed performance.

The JV100-160 is available in a bottle ink and a cartridge ink model. The 1L bottle ink model, available for the NON-EU region, comes in a 4 colour configuration, while the cartridge model comes in a 4 and 8 colour configuration.

EU MODEL

AS5

Eco Solvent Ink

Newly developed, most competitive 8 colour eco solvent ink with excellent weather ability and rub-fastness.

Packaging

600ml eco cartridge and 2L bags*

Colour

4 colours: CMYK
8 colours: CMYK Or Lk Lc Lm

Ink Type

Eco solvent ink for indoor and outdoor applications.

SS21

Eco Solvent ink

Benchmark high quality mild solvent ink with excellent weather ability and rub-fastness.

Packaging

2L bags*

Colour

4 colours: CMYK
8 colours: CMYK Or Lk Lc Lm

Ink type

Mild solvent ink for long lasting indoor and outdoor applications and vehicle wrappings.
